UL LISTED
12V / 24V

Led Power Supplies

UL Certified

AC/DC 110VAC 12V 24VDC LED Power Supply for all CPD products.

Contact us today to discuss your ideas and see how we can provide more service for you!

Spec Sheet
Get In Touch

FEATURES

  • Constant current / voltage design
  • Universal AC input / Full range
  • Withstand 300VAC surge input for 5 seconds
  • Protections: Short circuit / Over voltage
  • Cooling by free air convection
  • Plastic / aluminum case
  • UL listed
  • Suitable for LED lighting and moving sign applications
  • 100% full load burn-in test
  • Low cost, high reliability
  • 2 years warranty

Technical Information

Specifications
OUTPUTDC VOLTAGE5V12V24V
RATED CURRENT60A29A14.6A
CURRENT RANGE0 ~60A0 ~ 29A0 ~14.6A
RATED POWER252W348W350.4W
SETUP, RISE TIME1300ms, 50ms/230VAC 1300ms,50ms/115VAC at full load
HOLD UP TIME16ms/230VAC 12ms/115VAC at full load
INPUTVOLTAGE RANGE90 ~ 132VAC / 180 ~ 264VAC by switch 240 ~ 370VDC (switch on 230VAC)
FREQUENCY RANGE47 ~ 63Hz
INRUSH CURRENT60A/115VAC 60A/230VAC
ENVIRONMENTWORKING TEMP.-25 ~ +70℃(Refer to "Derating Curve")
WORKING HUMIDITY20 ~ 90% RH non-condensing
OTHERSDIMENSION215*115*30mm (L*W*H)
PACKING0.76Kg; 15pcs/12.4Kg/0.78CUFT
